TECHNICAL DATA

MAIN FEATURE

• Mechatronics and ergonomics design, small size, light weight, easy to operation
• The stylus drive unit can be stored within the main unit for standard measurement, or separated from the display unit by using the supplied cable which allows more flexible measurement in any orientation. The driver can be separated and reattached in one simple step.
• DSP chip control and data processing, high speed, low power consumption
• 22 Parameters: Ra ,Rz, Rq, Rt, Rp ,Rv, R3z, R3y, Rz(JIS), Rs, Rsk, Rsm, Rku, Rmr, Ry(JIS), Rmax,RPc, Rk, Rpk, Rvk, Mr1, Mr2
• Measurement range up to 160μm (can be optional to 320μm)
• 3.5 inches color graphic TFT touch screen, wide viewing angle, excellent readability and an intuitive rich display, it includes a backlight to improve visibility in dark environments
• Can be operated using buttons or touch screen
• It provide Bluetooth Capability , support wireless connection with mobile and mini printer.
• Built-in lithium-ion rechargeable battery and control circuit, high capacity, no memory effect, it works over 50 hours while fully charged, and there is remaining charge indicator, charging hint
• Large capacity data storage, 100 item of raw data and curves can be stored
• Real-time clock setting and display for easy data recording and storage
• With auto sleep, auto power off, power-saving features
• Reliable circuit and software design to preventing the motor stuck
• Language: Chinese and English switch freely
• All parameters or any of the parameters which set by users can be printed
• Optional accessories: Bluetooth capability, curved sensor, pinholes sensors, measurement, stand, extension rod, printer
• Portable Surface Roughness Tester KR310 complies with international standards ISO, DIN, ANSI, JIS

STANDARD DELIVERY

TMTeck Instrument Co., Ltd.(hereafter:TMTeck) is a leading NDT manufacturers and suppliers in Beijing China and provides innovative technologies and comprehensive know-how to benefit customers in a lot of countries around the world.Till now,TMTeck has been active in the areas of technology-driven inspection solutions that deliver productivity, quality and safety.

Began from the Ultrasonic Transducers and Coating Thickness Gauge ,now TMTeck has developed more than 10 series of testing instruments, including Ultrasonic Flaw Detector, Coating Thickness Gauge,Hardness Testers,Ultrasonic Thickness Gauge ,their accessories and other NDT instruments. These products are widely used in the analysis of materials that enable our customers to monitor, control and validate their critical processes and applications,also our goods has CE certificates.

TMTeck is committed to the maintenance of long-term partnership with our clients by offering unparalleled services, technology advice and assistance. We design and produce a wide range of high performance NDT equipment and accessories. With our continued emphasis on customer focus and global competitiveness, TMTeck has always been one of the top tier of world class companies when it comes to leading in NDT equipment. And we are developing new series products according to the market demand. We can offer good guarantee for our customers.
